Biological Split Film Woven Geotextile Seepage With UV Resistant

China Biological Split Film Woven Geotextile Seepage With UV Resistant supplier
Biological Split Film Woven Geotextile Seepage With UV Resistant supplier Biological Split Film Woven Geotextile Seepage With UV Resistant supplier Biological Split Film Woven Geotextile Seepage With UV Resistant supplier Biological Split Film Woven Geotextile Seepage With UV Resistant supplier

Large Image :  Biological Split Film Woven Geotextile Seepage With UV Resistant

Product Details:

Place of Origin: China
Brand Name: HongHuan
Certification: ISO9001
Model Number: SWG43

Payment & Shipping Terms:

Minimum Order Quantity: 5,000/m^2
Packaging Details: PVC or PP Fabric Rolls
Delivery Time: 45 days
Payment Terms: T/T, LC
Supply Ability: 8,000,000m^2/Month
Contact Now
Detailed Product Description
Application: Slop Protection Color: Black
Feature: High Tensile Strength/ Seepage Geotextile Type: Woven Geotextile
Material: Pp Product Name: PP Split Film Yarn Woven Geotextile
Sample: Yes



Biological Split Film Woven Geotextile Seepage With UV Resistant







Product Description:



Split Film Woven Geotextile is a kind of cost-effective woven geotextile made from Polypropylene slit film yarns. This geotextile is now mainly used for reinforcment and separation application . If you are building a road , constructing a parking lot, stabilizing material staging areas or repairing/installing  a gravel driveway, woven geotextile perform at a high level and save time and money. And in most cases, our woven geotextile offer an added advantage over any geogrid on separation function.





Specification Data Sheet :


PROPERTIES

TEST METHOD

UNIT

NOMINAL VALUE

 Mass Per Unit Area

ASTM D 5261

g/m2

430

 Tensile strength, MD

ASTM D 4595

kN/m

120

 Tensile strength, CD

ASTM D 4595

kN/m

85

 Elongation, MD

ASTM D 4595

%

25

 Elongation, CD

ASTM D 4595

%

25

 Apparent Opening Size

ASTM D 4751

mm

0.41

 Permittivity

ASTM D 4491

sec-1

NA

 Water Flow Rate

ASTM D 4491

l/min/m2

160

 Trapezoidal Tear Strength

ASTM D 4533

kN

0.84

 CBR Ejection Force

ASTM D 6241

kN

9.00

 UV Resistance

 (% retained after 500 hours)

ASTM D 4355

%

70

ROLL DIMENSIONS







Roll Width



m

5.85

Roll Length



m

70

Roll Weight



Kg

133





Product Function:



  • Embankments reinforcement
  • Earth reinforcement
  • Soft soil stabilization
  • Slop protection
  • Road contruction



Some Details Of Product:



           Biological Split Film Woven Geotextile Seepage With UV Resistant



Product Features:



  • Width Range From 3.81m to 8m
  • Low elongation
  • High strength
  • Resistance to the biological and chemical environments
  • Easy to install
  • Resistant to UV



Product Package and Storage:



  • Split film woven geotextiles are supplied on 4' cardboard cores and wrapped in black polyethylene sheeting .
  • Geotextile can be folded to a suitable width if it's needed .
  • All materials are stored indoors to protect them from exposure to UV.



            Biological Split Film Woven Geotextile Seepage With UV ResistantBiological Split Film Woven Geotextile Seepage With UV ResistantBiological Split Film Woven Geotextile Seepage With UV Resistant



Product Certification:



Biological Split Film Woven Geotextile Seepage With UV Resistant
