Geomembrane PP woven geotextile soft soil stabilization projects

Geomembrane PP woven geotextile soft soil stabilization projects
Geomembrane PP woven geotextile soft soil stabilization projects

Large Image :  Geomembrane PP woven geotextile soft soil stabilization projects

Product Details:
Place of Origin: China
Brand Name: HongHuan
Certification: ISO9001
Model Number: SWG33
Payment & Shipping Terms:
Minimum Order Quantity: 5,000/m^2
Packaging Details: PVC or PP Fabric Rolls
Delivery Time: 45 days
Payment Terms: T/T, LC
Supply Ability: 8,000,000m^2/Month
Detailed Product Description
Application: Soft Soil Stabilization Color: Black
Feature: High Tensile Strength/seepage Function: Reinforcement/ Separation
Geotextile Type: Woven Geotextile Material: Pp
Product Name: PP Woven Geotextile Sample: Yes
High Light:

geotextile stabilization fabric

,

geotextile landscape fabric



Geomembrane PP woven geotextile soft soil stabilization projects





Product Description:



Split Film Woven Geotextile is a kind of cost-effective woven geotextile made from Polypropylene slit film yarns. This geotextile is now mainly used for reinforcment and separation application . If you are building a road , constructing a parking lot, stabilizing material staging areas or repairing/installing  a gravel driveway, woven geotextile perform at a high level and save time and money. And in most cases, our woven geotextile offer an added advantage over any geogrid on separation function.





Specification Data Sheet :


PROPERTIES

TEST METHOD

UNIT

NOMINAL VALUE

 Mass Per Unit Area

ASTM D 5261

g/m2

330

 Tensile strength, MD

ASTM D 4595

kN/m

60

 Tensile strength, CD

ASTM D 4595

kN/m

60

 Elongation, MD

ASTM D 4595

%

25

 Elongation, CD

ASTM D 4595

%

25

 Apparent Opening Size

ASTM D 4751

mm

0.41

 Permittivity

ASTM D 4491

sec-1

NA

 Water Flow Rate

ASTM D 4491

l/min/m2

160

 Trapezoidal Tear Strength

ASTM D 4533

kN

0.6

 CBR Ejection Force

ASTM D 6241

kN

6.00

 UV Resistance

 (% retained after 500 hours)

ASTM D 4355

%

70

ROLL DIMENSIONS







Roll Width



m

5.85

Roll Length



m

100

Roll Weight



Kg

150





Some Details Of Product:



Geomembrane PP woven geotextile soft soil stabilization projects 0      Geomembrane PP woven geotextile soft soil stabilization projects 1     Geomembrane PP woven geotextile soft soil stabilization projects 2



Product Application:



  • Embankments reinforcement
  • Earth reinforcement
  • Soft soil stabilization
  • Slop protection
  • Road contruction



Product Package and Storage:



  • Split film woven geotextiles are supplied on 4' cardboard cores and wrapped in black polyethylene sheeting .
  • Geotextile can be folded to a suitable width if it's needed .
  • All materials are stored indoors to protect them from exposure to UV.
