PP Woven Geotextile Fabric for Reinforcement Filtration Separation

Large Image : PP Woven Geotextile Fabric for Reinforcement Filtration Separation

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	Honghuan
Model Number:	MWG&SWG

Payment & Shipping Terms:

Minimum Order Quantity:	100

Contact Now

Detailed Product Description

Material:	PP	Length:	50-100m/roll
Weight:	100-800g/sqm	Width:	2-6m
Tensile Strength MD:	38.5-105.1 KN/m	Tensile Strength CD:	35.9-96.3 KN/m
Elongation MD:	25%	Elongation CD:	25%
Tensile Strength 2% MD:	7-21 KN/m	Tensile Strength 2% CD:	8.6-25 KN/m
Tensile Strength 5% MD:	17.7-52.5 KN/m	Tensile Strength 5% CD:	19.8-53 KN/m
Factory Seam Strength:	18.4-52.5 KN/m	Apparent Opening Size:	0.43-0.6 Mm
Permittivity:	0.04-0.9 Sec-1
Highlight:	PP woven geotextile reinforcement fabric , woven geotextile filtration fabric , geotextile separation fabric for construction

PP Woven Geotextiles Geotextile Tube

Product Attributes

Attribute	Value
Geotextile Type	Woven Geotextiles
Type	Geotextiles
Material	PP
Color	Customized
Application	Water Conservancy, Railway, Highway
Length	50-100m/roll (at Request)
Weight	100-800g/sqm
Width	2-6m
Usage	Reinforcement, Filtration, Separation
Certificate	ISO9001
Function	Filtration, Reinforcement, Separation, Protection

Product Description

Woven Geotextile MWG® is a mono-filament woven geotextile incorporating round strands that are extruded. Composed of high-tenacity polypropylene yarns woven into a stable network, this product is ideal for applications requiring both strength and filtration, such as shoreline rip rap applications.

Product Specifications

PROPERTIES	TEST METHOD	UNIT	MWG270	MWG370	MWG570	MWG665	MWG770
Tensile Strength, MD	ASTM D 4595	kN/m	38.5	52.5	70	70	105.1
Tensile Strength, CD	ASTM D 4595	kN/m	35.9	47.3	70	96.3	84
Elongation, MD	ASTM D 4595	%	25	25	25	25	25
Elongation, CD	ASTM D 4595	%	25	25	25	25	25
Tensile Strength at 2%, MD	ASTM D 4595	kN/m	7	11	14	17.5	21
Tensile Strength at 2%, CD	ASTM D 4595	kN/m	8.6	12.3	19.3	25	22.8
Tensile Strength at 5%, MD	ASTM D 4595	kN/m	17.7	21.9	35	35	52.5
Tensile Strength at 5%, CD	ASTM D 4595	kN/m	19.8	22.8	39.4	53	47.1
Factory Seam Strength	ASTM D 4884	kN/m	18.4	25.1	37.5	52.5	43.8
Apparent Opening Size	ASTM D 4751	mm	0.6	0.43	0.6	0.43	0.6
Permittivity	ASTM D 4491	sec-1	0.7	0.9	0.4	0.26	0.04
Water Flow Rate	ASTM D 4491	l/min/m2	2037	1630	1222	815	611
UV Resistance (% retained after 500 hours)	ASTM D 4355	%	80	80	80	70	80

*The values given are Minimum Average Values except elongation and UV resistance. Elongation is a Maximum Value and UV is a typical value.
*Mass per unit area has a tolerance of ±10%.
This information is provided for reference purposes only and is not intended as a warranty or guarantee. Ningbo HongHuan assumes no liability in connection with the use of this information. Specifications subject to change without notice.
