Woven PP Geotextile Fabric for Railway 100-800g/m2 Tear-Resistant

Large Image : Woven PP Geotextile Fabric for Railway 100-800g/m2 Tear-Resistant

Product Details:

Place of Origin:	China
Brand Name:	Honghuan
Model Number:	MWG

Payment & Shipping Terms:

Minimum Order Quantity:	100

Contact Now

Detailed Product Description

Geotextile Type:	Woven Geotextiles	Material:	PP
Width:	2-6m	Length:	50-100m
Weight:	100-800g/m2	Tensile Strength MD:	38.5-105.1 KN/m
Tensile Strength CD:	35.9-96.3 KN/m	Elongation:	25%
Tensile Strength 2% MD:	7-21 KN/m	Tensile Strength 2% CD:	8.6-25 KN/m
Tensile Strength 5% MD:	17.7-52.5 KN/m	Tensile Strength 5% CD:	19.8-53 KN/m
Factory Seam Strength:	18.4-52.5 KN/m	Apparent Opening Size:	0.43-0.6 Mm
Permittivity:	0.04-0.9 Sec-1
Highlight:	woven PP geotextile fabric for railway , tear-resistant woven geotextile fabric , 100-800g/m2 woven geotextile fabric

Woven Geotextile MWG®

Product Overview

Mono-filament Woven Geotextile incorporates round strands that are extruded. Composed of high-tenacity polypropylene yarns woven into a stable network, this geotextile is ideal for applications requiring both strength and filtration, such as shoreline rip rap applications.

Product Attributes

Attribute	Value
Geotextile Type	Woven Geotextiles
Material	PP
Type	Other Earthwork Products
Color	Requirement
Width	2-6m
Length	50-100m
Weight	100-800g/m2
Application	Railway
Features	Tear-Resistant

Technical Specifications

PROPERTIES	TEST METHOD	UNIT	MWG270	MWG370	MWG570	MWG665	MWG770
Tensile Strength, MD	ASTM D 4595	kN/m	38.5	52.5	70	70	105.1
Tensile Strength, CD	ASTM D 4595	kN/m	35.9	47.3	70	96.3	84
Elongation, MD	ASTM D 4595	%	25	25	25	25	25
Elongation, CD	ASTM D 4595	%	25	25	25	25	25
Tensile Strength at 2%, MD	ASTM D 4595	kN/m	7	11	14	17.5	21
Tensile Strength at 2%, CD	ASTM D 4595	kN/m	8.6	12.3	19.3	25	22.8
UV Resistance (% retained after 500 hours)	ASTM D 4355	%	80	80	80	70	80

*The values given are Minimum Average Values except elongation and UV resistance. Elongation is a Maximum Value and UV is a typical value.
*Mass per unit area has a tolerance of ±10%.
This information is provided for reference purposes only and is not intended as a warranty or guarantee. Specifications subject to change without notice.

Applications

Weed block for landscaped garden beds
Permeable liners for planters (stops soil erosion)
Weed control under wooden decking
Geotextile for separating aggregate/soils under walkway blocks or bricks
Assists in preventing paving from settling unevenly
Landscape fabric prevents soil erosion
