Tear-Resistant Woven Geotextile Fabric for Railway Applications

Large Image : Tear-Resistant Woven Geotextile Fabric for Railway Applications

Product Details:

Place of Origin:	China
Brand Name:	Honghuan
Model Number:	MWG

Payment & Shipping Terms:

Minimum Order Quantity:	100

Contact Now

Detailed Product Description

Material:	PP	Weight:	100-800g/m2
Length:	50-100m	Width:	2-6m
Tensile Strength MD:	38.5-105.1 KN/m	Tensile Strength CD:	35.9-96.3 KN/m
Elongation MD:	25%	Elongation CD:	25%
Tensile Strength 2% MD:	7-21 KN/m	Tensile Strength 2% CD:	8.6-25 KN/m
Tensile Strength 5% MD:	17.7-52.5 KN/m	Tensile Strength 5% CD:	19.8-53 KN/m
Factory Seam Strength:	18.4-52.5 KN/m	Apparent Opening Size:	0.43-0.6 Mm
Permittivity:	0.04-0.9 Sec-1
Highlight:	tear-resistant woven geotextile fabric , woven geotextile for railways , durable geotextile fabric railway

Hot Selling Tear-Resistant Geotube Dewatering High Tensile Geotextile Geotube Dewatering

Product Attributes

Attribute	Value
Geotextile Type	Woven Geotextiles
Type	Geotextiles
Material	PP
Features	Tear-Resistant
Keyword	Geo Textile Bag
Weight	100-800g/m2
Length	50-100m
Width	2-6m
Color	Requirement
Product name	woven geotextiles
Application	Railway

Product Description

Woven Geotextile MWG® is a mono-filament woven geotextile incorporating round strands that are extruded. Composed of high-tenacity polypropylene yarns woven into a stable network, this product is ideal for applications requiring both strength and filtration, such as shoreline rip rap applications.

Product Specifications

PROPERTIES	TEST METHOD	UNIT	MWG270	MWG370	MWG570	MWG665	MWG770
Tensile Strength, MD	ASTM D 4595	kN/m	38.5	52.5	70	70	105.1
Tensile Strength, CD	ASTM D 4595	kN/m	35.9	47.3	70	96.3	84
Elongation, MD	ASTM D 4595	%	25	25	25	25	25
Elongation, CD	ASTM D 4595	%	25	25	25	25	25
Tensile Strength at 2%, MD	ASTM D 4595	kN/m	7	11	14	17.5	21
Tensile Strength at 2%, CD	ASTM D 4595	kN/m	8.6	12.3	19.3	25	22.8
Tensile Strength at 5%, MD	ASTM D 4595	kN/m	17.7	21.9	35	35	52.5
Tensile Strength at 5%, CD	ASTM D 4595	kN/m	19.8	22.8	39.4	53	47.1
Factory Seam Strength	ASTM D 4884	kN/m	18.4	25.1	37.5	52.5	43.8
Apparent Opening Size	ASTM D 4751	mm	0.6	0.43	0.6	0.43	0.6
Permittivity	ASTM D 4491	sec-1	0.7	0.9	0.4	0.26	0.04
Water Flow Rate	ASTM D 4491	l/min/m2	2037	1630	1222	815	611
UV Resistance (% retained after 500 hours)	ASTM D 4355	%	80	80	80	70	80

*The values given are Minimum Average Values except elongation and UV resistance. Elongation is a Maximum Value and UV is a typical value. *Mass per unit area has a tolerance of ±10%. This information is provided for reference purposes only and is not intended as a warranty or guarantee. Ningbo HongHuan assumes no liability in connection with the use of this information. Specifications subject to change without notice.

Applications

Weed block for landscaped garden beds
Permeable liners for planters (stops soil erosion)
Weed control under wooden decking
Geotextile for separating aggregate/soils under walkway blocks or bricks
Assists in preventing paving from settling unevenly
Landscape fabric prevents soil erosion

Which payment do you accept?

For your convenience, our payment options include L/C, TT, Westunion, and PayPal.

Are you willing to provide samples?

We are glad to provide samples if we have identical or similar products in our warehouse.

May I get a cheaper price?

We offer favorable discounts for large quantity orders.

Do you accept customized designs?

Yes, we welcome customized design requests.

How to contact us?

Select a product and leave a message, or see our contact details for more information.
