PP Woven Geotextile Fabric for Erosion Control

Large Image : PP Woven Geotextile Fabric for Erosion Control

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	Honghuan
Certification:	ISO9001
Model Number:	MWG

Payment & Shipping Terms:

Minimum Order Quantity:	10000

Contact Now

Detailed Product Description

Material:	PP	Tensile Strength MD:	38.5-105.1 KN/m
Tensile Strength CD:	35.9-96.3 KN/m	Elongation MD:	25%
Elongation CD:	25%	Tensile Strength 2% MD:	7-21 KN/m
Tensile Strength 2% CD:	8.6-25 KN/m	Tensile Strength 5% MD:	17.7-52.5 KN/m
Tensile Strength 5% CD:	19.8-53 KN/m	Factory Seam Strength:	18.4-52.5 KN/m
Apparent Opening Size:	0.43-0.6 Mm	Permittivity:	0.04-0.9 Sec-1
Water Flow Rate:	611-2037 L/min/m2	UV Resistance:	70-80% Retained
Geotextile Type:	Mono-filament Woven
Highlight:	PP woven geotextile fabric , woven geotextile for erosion control , PP geotextile erosion control fabric

China Cheap Popular Geotextile Bag and Tube

Product Attributes

Attribute	Value
Warranty	NONE
After-sale Service	NONE
Project Solution Capability	NONE
Application	Other
Design Style	Modern
Geotextile Type	Woven Geotextiles
Type	Woven Geotextiles, Other Earthwork Products
Material	PP

Product Description

Woven Geotextile MWG® is a mono-filament woven geotextile incorporating round strands that are extruded. Composed of high-tenacity polypropylene yarns woven into a stable network, this product is ideal for applications requiring both strength and filtration, such as shoreline rip rap applications.

Product Specifications

PROPERTIES	TEST METHOD	UNIT	MWG270	MWG370	MWG570	MWG665	MWG770
Tensile Strength, MD	ASTM D 4595	kN/m	38.5	52.5	70	70	105.1
Tensile Strength, CD	ASTM D 4595	kN/m	35.9	47.3	70	96.3	84
Elongation, MD	ASTM D 4595	%	25	25	25	25	25
Elongation, CD	ASTM D 4595	%	25	25	25	25	25
Tensile Strength at 2%, MD	ASTM D 4595	kN/m	7	11	14	17.5	21
Tensile Strength at 2%, CD	ASTM D 4595	kN/m	8.6	12.3	19.3	25	22.8
Tensile Strength at 5%, MD	ASTM D 4595	kN/m	17.7	21.9	35	35	52.5
Tensile Strength at 5%, CD	ASTM D 4595	kN/m	19.8	22.8	39.4	53	47.1
Factory Seam Strength	ASTM D 4884	kN/m	18.4	25.1	37.5	52.5	43.8
Apparent Opening Size	ASTM D 4751	mm	0.6	0.43	0.6	0.43	0.6
Permittivity	ASTM D 4491	sec-1	0.7	0.9	0.4	0.26	0.04
Water Flow Rate	ASTM D 4491	l/min/m2	2037	1630	1222	815	611
UV Resistance (% retained after 500 hours)	ASTM D 4355	%	80	80	80	70	80

*The values given are Minimum Average Values except elongation and UV resistance. Elongation is a Maximum Value and UV is a typical value.
*Mass per unit area has a tolerance of ±10%.

This information is provided for reference purposes only and is not intended as a warranty or guarantee. Ningbo HongHuan assumes no liability in connection with the use of this information. Specifications subject to change without notice.

Applications

Weed block for landscaped garden beds
Permeable liners for planters (stops soil erosion)
Weed control under wooden decking
Geotextile for separating aggregate/soils under walkway blocks or bricks
Assists in preventing paving from settling unevenly
Landscape fabric prevents soil erosion
