PP Woven Geotextile Fabric 2-6m Width for Separation Filtration

Large Image : PP Woven Geotextile Fabric 2-6m Width for Separation Filtration

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	Honghuan
Model Number:	MWG

Payment & Shipping Terms:

Minimum Order Quantity:	100

Contact Now

Detailed Product Description

Material:	PP	Width:	2-6m
Weight:	100-800g/m2	Length:	50-100m
Tensile Strength MD:	38.5-105.1 KN/m	Tensile Strength CD:	35.9-96.3 KN/m
Elongation MD:	25%	Elongation CD:	25%
Tensile Strength 2% MD:	7-21 KN/m	Tensile Strength 2% CD:	8.6-25 KN/m
Tensile Strength 5% MD:	17.7-52.5 KN/m	Tensile Strength 5% CD:	19.8-53 KN/m
Factory Seam Strength:	18.4-52.5 KN/m	Apparent Opening Size:	0.43-0.6 Mm
Permittivity:	0.04-0.9 Sec-1
Highlight:	PP woven geotextile fabric , woven geotextile for separation , geotextile fabric 2-6m width

Geotextile Fabric with Low Price, Factory Sales Geotextile Tube

Product Overview

Woven Geotextile MWG® is a mono-filament woven geotextile incorporating round strands that are extruded. Composed of high-tenacity polypropylene yarns woven into a stable network, this product is ideal for applications requiring both strength and filtration, such as shoreline rip rap applications.

Key Features

Material: Polypropylene (PP)
Type: Woven Geotextiles
Tear-resistant construction
Available in widths from 2-6m
Weight options: 100-800g/m²
Length options: 50-100m
Custom colors available

Technical Specifications

PROPERTIES	TEST METHOD	UNIT	MWG270	MWG370	MWG570	MWG665	MWG770
Tensile Strength, MD	ASTM D 4595	kN/m	38.5	52.5	70	70	105.1
Tensile Strength, CD	ASTM D 4595	kN/m	35.9	47.3	70	96.3	84
Elongation, MD	ASTM D 4595	%	25	25	25	25	25
Elongation, CD	ASTM D 4595	%	25	25	25	25	25
Tensile Strength at 2%, MD	ASTM D 4595	kN/m	7	11	14	17.5	21
Tensile Strength at 2%, CD	ASTM D 4595	kN/m	8.6	12.3	19.3	25	22.8
Factory Seam Strength	ASTM D 4884	kN/m	18.4	25.1	37.5	52.5	43.8
Apparent Opening Size	ASTM D 4751	mm	0.6	0.43	0.6	0.43	0.6
UV Resistance (% retained after 500 hours)	ASTM D 4355	%	80	80	80	70	80

*The values given are Minimum Average Values except elongation and UV resistance. Elongation is a Maximum Value and UV is a typical value.
*Mass per unit area has a tolerance of ±10%.

Applications

Weed block for landscaped garden beds
Permeable liners for planters (stops soil erosion)
Weed control under wooden decking
Separation of aggregate/soils under walkway blocks or bricks
Prevents paving from settling unevenly
Soil erosion prevention in landscaping

Frequently Asked Questions

Which payment methods do you accept?

We accept L/C, TT, West Union, and PayPal for your convenience.

Are you willing to provide samples?

We're happy to provide samples if we have identical or similar products in our warehouse.

Can I get a cheaper price for large quantities?

Yes, we offer favorable discounts for large quantity orders.

Do you accept customized designs?

Yes, we welcome customized design requests.

How can I contact you?

Please select a product and leave a message, or see our contact details for more information.
