PP Woven Geotextile Fabric for Water Conservancy and Slope Protection

Large Image : PP Woven Geotextile Fabric for Water Conservancy and Slope Protection

Product Details:

Place of Origin:	China
Brand Name:	Honghuan
Model Number:	MWG

Payment & Shipping Terms:

Minimum Order Quantity:	100

Contact Now

Detailed Product Description

Material:	PP	Weight:	100-800g/m2
Length:	50-100m/roll	Width:	2-6m
Tensile Strength MD:	38.5-105.1 KN/m	Tensile Strength CD:	35.9-96.3 KN/m
Elongation MD:	25%	Elongation CD:	25%
Tensile Strength 2% MD:	7-21 KN/m	Tensile Strength 2% CD:	8.6-25 KN/m
Tensile Strength 5% MD:	17.7-52.5 KN/m	Tensile Strength 5% CD:	19.8-53 KN/m
Factory Seam Strength:	18.4-52.5 KN/m	Apparent Opening Size:	0.43-0.6 Mm
UV Resistance:	70-80% Retained After 500 Hours
Highlight:	PP woven geotextile fabric for slope protection , woven geotextile fabric for water conservancy , PP geotextile fabric for erosion control

High Quality Sludge Dewatering Mono-filament PP Polypropylene Fiber Geotextile Bag

Product Attributes

Attribute	Value
Material	PP (Polypropylene)
Type	Woven Geotextiles
Weight	100-800g/m²
Length	50-100m/roll (customizable)
Width	2-6m
Color	Customizable
Features	Tear-Resistant
Applications	Water Conservancy, Railway, Highway, Ecological Slope Protection
After-sale Service	Online technical support

Product Description

MWG® Mono-filament Woven Geotextile is manufactured from high-tenacity polypropylene yarns woven into a stable network structure. This construction ensures the yarns maintain their relative position, making it ideal for applications requiring both strength and filtration capabilities, such as shoreline rip rap applications.

Technical Specifications

PROPERTIES	TEST METHOD	UNIT	MWG270	MWG370	MWG570	MWG665	MWG770
Tensile Strength, MD	ASTM D 4595	kN/m	38.5	52.5	70	70	105.1
Tensile Strength, CD	ASTM D 4595	kN/m	35.9	47.3	70	96.3	84
Elongation, MD	ASTM D 4595	%	25	25	25	25	25
Elongation, CD	ASTM D 4595	%	25	25	25	25	25
Tensile Strength at 2%, MD	ASTM D 4595	kN/m	7	11	14	17.5	21
Tensile Strength at 5%, MD	ASTM D 4595	kN/m	17.7	21.9	35	35	52.5
Apparent Opening Size	ASTM D 4751	mm	0.6	0.43	0.6	0.43	0.6
Permittivity	ASTM D 4491	sec-1	0.7	0.9	0.4	0.26	0.04
UV Resistance (% retained after 500 hours)	ASTM D 4355	%	80	80	80	70	80

*The values given are Minimum Average Values except elongation and UV resistance. Elongation is a Maximum Value and UV is a typical value.
*Mass per unit area has a tolerance of ±10%.
This information is provided for reference purposes only and is not intended as a warranty or guarantee. Specifications subject to change without notice.
