Premium PP Warp Knitted Geotextile Durable Warp Knitted Polypropylene Material for Road Construction Reinforcement

Large Image : Premium PP Warp Knitted Geotextile Durable Warp Knitted Polypropylene Material for Road Construction Reinforcement

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	Chengmei

Payment & Shipping Terms:

Minimum Order Quantity:	1000

Contact Now

Detailed Product Description

Material:	Pp, PP PET	Feature:	Anti-Aging
After-sale Service:	Other	Length:	Custom, 50-200m
Project Solution Capability:	Others	Application:	Road
Design Style:	Modern	Geotextile Type:	Woven Geotextiles
Color:	Black	Width:	Accept Customer-made
Usage:	Road Railway Construction	Function:	Filtration ,separation,drainage, Reinforcement, Stabilization
Sample:	Free	Certificate:	ISO9001:2008
MOQ:	20GP	Thickness:	1-5mm
Highlight:	PP warp knitted geotextile for road construction , durable polypropylene geotextile fabric , woven geotextile reinforcement material

Premium PP Warp Knitted Geotextile Durable Warp Knitted Polypropylene Material for Road Construction Reinforcement 0

Premium PP Warp Knitted Geotextile Durable Warp Knitted Polypropylene Material for Road Construction Reinforcement 2

Premium PP Warp Knitted Geotextile Durable Warp Knitted Polypropylene Material for Road Construction Reinforcement 4

Geotextiles include a variety of synthetic polymer materials that are specially fabricated to be used in geotechnical, geoenvironmental, hydraulic and transportation engineering applications. It is convenient to identify the primary function of a geotextile as being one of: separation, filtration, drainage, reinforcement, fluid/gas containment, or erosion control. In some cases the geosynthetic may serve dual functions.

Mechanical Properties	Test Method	Minimum Average(English)	Minimum Average(Metric)
Wide Width Tensile Strength (MD x CD)	ASTM D-4595	4800*4800 Ibs/ft	70*70 kN/m
Grab Tensile Strength (MD x CD)	ASTM D-4632	Ibs	kN
Grab Tensile Elongation	ASTM D-4632	25%	25%
Trapezoidal Tear	ASTM D-4533	180*180 Ibs	801*801 N
CBR Puncture	ASTM D-6241	2000 Ibs	8896 N
Apparent Opening Size(AOS)	ASTM D-4751	30 US Std.Sieve	0.6 mm
Permittivity	ASTM D-4491	0.4 sec-1	0.4 sec-1
Water Flow Rate	ASTM D-4491	30 gal/min/ft²	1222 L/min/m²
UV Resistance (% retained after 500 hours)	ASTM D-4355	80%	80%

Premium PP Warp Knitted Geotextile Durable Warp Knitted Polypropylene Material for Road Construction Reinforcement 8

Premium PP Warp Knitted Geotextile Durable Warp Knitted Polypropylene Material for Road Construction Reinforcement 10

Premium PP Warp Knitted Geotextile Durable Warp Knitted Polypropylene Material for Road Construction Reinforcement 12

Premium PP Warp Knitted Geotextile Durable Warp Knitted Polypropylene Material for Road Construction Reinforcement 14

Premium PP Warp Knitted Geotextile Durable Warp Knitted Polypropylene Material for Road Construction Reinforcement 16

Premium PP Warp Knitted Geotextile Durable Warp Knitted Polypropylene Material for Road Construction Reinforcement 18

A: Are you manufacturer?

B: Yes,ae are factory.

A: What's the leading time?

B: Usually 15-25 days.

A: What's your payment term?

B: T/T,L/C,WestUnion and some other convinient payment way.

A: How can I visit your factory?

B: Fly to Ningbo Airpot,We'll send driver to pick you up.
